The TENOR is a Mid B wing which sets new standards in dynamic performance, passive safety and aerodynamic construction.
The additional mini ribs in the leading edge double the cell number in the critical area of the aerofoil. Together with the optimised double zigzag 3D shaping the surface finish reaches a new level of perfection.
Although the TENOR is a very robust wing (Dominico 30D/20D cloth and internal stitching of trailing edge mini ribs), the innovative internal construction reduces the weight effectively.
This wing is very stable at speed and has plenty of safety when it’s getting rough: the TENOR is built to expand your horizons.
Designer's Note
The TENOR is based on the SYMPHONIA, combining a very safe concept with some additional features to improve performance and speed. The additional ribs in the leading edge are the step forward in form stability. The new airfoil is offering a good climbing performance, even the wing being smaller. The reduced size and higher wing loading is moving the polar towards speed performance. So the TENOR is designed to reach the horizon.
Technical Data
TENOR | ||||||
size | XS 17 | S 19 | M 21 | L 23 | XL 25 | |
number of cells | 50 / 100 | 50 / 100 | 50 / 100 | 50 / 100 | 50 / 100 | |
projected span | m | 8.0 | 8.41 | 8.81 | 9.21 | 9.61 |
projected area | m² | 17.45 | 19.25 | 21.15 | 23.09 | 25.12 |
projected aspect ratio | 3.67 | 3.67 | 3.67 | 3.67 | 3.67 | |
flat span | m | 10.29 | 10.81 | 11.33 | 11.84 | 12.35 |
flat area | m² | 20.6 | 22.74 | 24.98 | 27.27 | 29.67 |
flat aspect ratio | 5.14 | 5.14 | 5.14 | 5.14 | 5.14 | |
line length | m | 6.13 | 6.44 | 6.75 | 7.06 | 7.36 |
total line length | m | 226.6 | 238 | 249.5 | 260.7 | 271.9 |
maximum chord | m | 2.49 | 2.62 | 2.74 | 2.87 | 2.99 |
minimum chord | m | 0.59 | 0.62 | 0.65 | 0.68 | 0.71 |
weight | kg | 4.1 | 4.4 | 4.7 | 5.0 | 5.4 |
recommend weight range | kg | 50-75 | 65-85 | 75-95 | 90-110 | 105-130 |
certification (EN/LTF) | B | B | B | B | B | |
material top-, buttomsail, inside | Dominico 30D, 20D, 30D | |||||
risers | 3+1 | |||||
riser length | mm | 500 | 500 | 540 | 540 | 540 |
speedway | mm | 130 | 150 | 170 | 170 | 170 |
Paratroc’s review – Phi Tenor light - test in flight
(conf: Tenor light 21 + advance lightness 3, Skyman ultra-cross 100 reserve, total weight = 92kg)
Phi is a new brand making its own way onto the market, but it doesn’t mean that they come from nowhere, its creator Papesh is probably one of the best designers in the world. He created the software currently used by Advance and Nova (he has been the designer for several years).
The Tenor light is a B access light – Aspect ratio = 5.14
Weight/size 25m² - called 21 because it’s 21m² projected (75-105kg) = 3.4kg!!!
For information, the Tenor light is a lighter version of the Tenor (4.7kg).
The Symphonia, the En A wing from the same brand is also a Tenor but lighter in-flight weight, so even accelerated the Symphonia stays En A.
So here we got 3 reviews in 1.
Let’s begin with the minus point … the carrying bag:
Can we call it like this? Half fast bag, half carrying bag, this bag is used to stuff it with the glider, but gives you no comfort (no ventral strap and no maintain in the back…) Anyway, you won’t travel a lot with that.
The glider:
50 cells but 100 ribs!!! There is a second rib in the middle of the cell (without cell walls), 5 closed cells on stab.
It’s something never seen before for a B access.
The leading edge is a shark nose type, tight openings, very rigid reinforced simple ribs on the sides and middle of the cells. You know you got a nice mouth :D
The trailing edge, thin polyester braid and the usual Velcro opening to empty the twigs. Little reinforcement bands on all the span of the wing between the lined cells. Different look than the other brands, you can recognize it with the diagonal stripes. The Tenor light is only available in white, with blue or red stripes.
The fabric used is the best one you can find = Porcher 32g for the leading ledge and 27g for the rest. It’s the same fabric that uses Advance for the Pi2 and the Xi.
Lines and risers:
3 low lines (7 low lines, stab included), divided C at the top (3 fake C-D lines), long wiring except in stab, weirdly, giving us an orphan line on each extremity. All the lines are coated except the upper level, and that’s an achievement for a 3.2kg wing with thin and simple risers. A (1) + A' (1) + B (2+stab) + C (2) - Break lines with O ring system for more precision.
The Tenor light is also available with standard risers: little links for the risers with a plastic casted piece used to fix the lines. O ring system for the accelerator on the B/C. Supple handle with ceramic rings, magnets and swivels.
Or light risers = same thickness, with straps but without A’ for the ear kit with Dyneema connections replacing the links – light grip with no magnet.
Line untangling:
Super easy, no grip, you can untangle with a single shake. You know, with 7 low lines, it’s so easy that you can’t miss.
Take off:
The lines are very long ... you are 7m away from the wing! Although, with a bit of wind, the wing lifts without even using the risers!
With no wind, it lifts nice and steadily, no problem. With a strong wind, the wing flaps a little bit but it doesn’t rip off or surpass you. Despite her lightness, you feel the glider, the take off is instant and reassuring .
in-Flight:
20cm before action point… it’s way too much! Adding that to a very long break range... even with a break wrap, I can’t act properly in traction. So, this is an access B that doesn’t punish too much for your mistakes, but if you want some reactivity, you’ll need to shorten the breaks.
Surely, I just tried the big sister, the Maestro, I feel it weird to use a beginner’s paraglider, of course the Tenor is made for beginner,
I haven't tried the Symphonia, just simply because it’s the same glider with a lower total weight, but honestly, I would advise a beginner to choose the total weight of the Tenor instead of the Symphonia.
Its behavior in flying reminds me of the Hook 5 (which is also in A non accelerated) but the Tenor has a slower reaction, even better for the beginners.
The damping of the pitch is insanely good.
After several minutes of thermal, I started understanding how to keep it in the turn (the wing is really stable spiral)
The wing is damped but as it’s a light you can feel the information in the thermal.
Maneuvers:
Pitch: you need to force a little bit (real hard point) to create a large movement, but stabilizes instantly, that’s lit.
Ears: there’s only 2 A lines, 1A + 1A' the ears are pretty big, pretty physical and re-open even no need to pump, and but scrapping the other lines – because of the profile.
Roll: the glider is slow to enter in the turn, it accelerates slowly after one turn, then faster, when you release, it naturally goes out without countering almost even going the other way, because of its pitch damp that prevents the wing from shooting.
To exit a 360, you’ll need to break the side of the turn to counter the reverse-roll.
You’ll need to time correctly your thermal turns with your harness in order to compensate the stability of the wing, anyway, the turn stay flat. You need to fly without holding outside the turns.
Global grade = 4/5 – Tenor light
5/5 – Symphonia
Let me explain, the first one, its wing is really good, like the second one, there’s a risk that it will be too much amortized. As a mountain calm wing, you’ll love it!
The Tenor (light) is made for talented beginners and young pilots who want a light and safe wing.
The design is really nice and top quality. 3.2kg with coated lines with Skytex 32 on the trailing edge, perfect.
Personal opinion: that Tenor light is an excellent glider for everybody because it’s compact, it has strong lines that withstand pebbles giving us a really good passive security. This is for all of you who wanted a Pi2 with coated lines.
I recommend using it with an Advance Easiness 3, your bag will weight 7-8kg (reserve included).
Be on top of the Total weight range or even above the top !
